FTTH Cable Production: Manufacturing Process Explained
Quick fact: more than 70% of U.S. broadband rollouts now depend on fiber networks that require precise manufacturing to hit performance targets.
Shanghai Weiye OFC Equipment handles end-to-end compact fiber unit manufacturing, from selecting brand fibers like Fujikura® or Corning® SMF-28e to final test reports that guarantee full quality assurance.
Our FTTH drop designs fit aerial, underground, and direct-buried installation, with low-smoke zero-halogen (LSZH), PVC, and polyethylene (PE) jacket options and configurations from 1–4 cores. We offer single-mode OS1/OS2 and OM2–OM4 grades plus ITU-T G.652D and G.657 variants, Pantone-matched sheath colors, and logo printing.
Automated machines and high-precision equipment keep line speed steady and keep repeatability high. Typical lead times are four to five days for orders under 100 km and 7–10 days under 500 km, with an min. order of 1 km and warranty for free replacement on quality issues.
Continue to see how materials, testing, and support work together to reduce lifecycle cost and pair the right product with your network.
- Shanghai Weiye OFC Equipment provides full manufacturing with lab validation for United States projects.
- Multiple jacket choices and fiber grades fit indoor/outdoor environments.
- Automated lines and machines deliver stable quality and reliable optical performance.
- Quick lead times, low MOQ, and recognized brand fibers support reliable procurement planning.
- Comprehensive test reports and after-sales warranty back product reliability and compliance documentation needs.
FTTH Manufacturing Expertise by Shanghai Weiye OFC Equipment
When project timelines and performance matter, Shanghai Weiye OFC Equipment delivers tailored drop solutions with complete test documentation.
As a focused supplier and manufacturer, Shanghai Weiye OFC Equipment combines purpose-built equipment with stringent material control. We provide customized service and products for residential and MDU rollouts. Every order comes with full QA coverage and complete test reports.
Our lab performs high heat, salt spray, and vibration tests to validate durability. Jacket options include LSZH, PVC, and PE. Designs cover bow-type flat and self-supporting styles and use brand fibers such as Fujikura and Corning® SMF-28e.
- Documented line control and production checks for fully auditable shipments.
- Technical support for requirements, pilots, and scaling.
- Modern fixtures and calibration minimize variation so every cable meets operator standards.
How We Produce FTTH Cable
At Shanghai Weiye OFC Equipment, manufacturing steps are built around network requirements, combining brand fiber choices with disciplined test flows.
Selecting Optical Fiber and Brands
We select Fiber coloring machine to bend radius, attenuation, and deployment type. Options include OS1/OS2 and OM2–OM4 and ITU-T G.652D, G.657.A1/A2. Brand fibers such as Fujikura and Corning SMF-28e are offered to satisfy sourcing standards.
Strength Member Options
Strength members use dielectric FRP or metallic steel wire. FRP is preferred where non-conductivity is necessary. Steel wire provides tensile strength for long-span aerial runs and bonding/grounding needs.
Jacket Options and Control
Jacket options include LSZH for indoor flame safety, PVC for flexibility and ease of handling, and PE for UV/moisture resistance outdoors. Tight process control of extruder temperature and capstan speed keeps line speed stable and critical dimensions.
| Component | Dielectric FRP | Steel wire |
|---|---|---|
| Use case | Electrical isolation | High-tension aerial runs |
| Advantage | Lightweight, inert | Very high tensile strength |
| Installer note | Simple terminations | Requires grounding |
In-Process and Final Testing
Inline geometry and concentricity checks run during manufacturing. Final optical tests verify loss and reflectance. Each order ships with a 100% test report and lab results from high-temperature, salt fog, and vibration trials to qualify field handling and drop terminations.
Typical lead times are under 100 km in 4–5 days and under 500 km in 7–10 days. Lot records and FAI approvals provide traceability and compliance for U.S. programs.
FTTH Drop Designs We Build
Shanghai Weiye OFC Equipment provides a focused portfolio of drop designs that fit indoor risers and long aerial runs. Each option pairs tested materials with geometry tuned for field termination and consistent optical performance.
The bow-type flat drop cable minimizes footprint for risers and conduit. It reduces bend loss for easy routing in hallways and MDUs.
Aerial Self-Supporting Options
Self-supporting FTTH drop designs use a messenger element to handle tension. Choose dielectric FRP for electrical isolation or steel messenger when bonding and extra tensile strength are required.
Layouts & Strength Members
We provide both dielectric and metallic strength member configurations to meet safety/EMI requirements. Center loose tube and unitube flat types balance crush resistance and compact fiber unit for quick termination.
Indoor vs Outdoor Jackets
Jacket choices include LSZH for flame-retardant, low-smoke indoor use and PE for outdoor UV and moisture resilience. Each family is qualified for mechanical and optical quality before shipment.
| Design | Application | Strength element | Sheath |
|---|---|---|---|
| Bow-type flat | Indoor risers, MDUs | FRP (dielectric) | LSZH |
| Self-supporting | Overhead spans | Steel wire or FRP | Polyethylene |
| Center loose tube | Higher-count builds | Dielectric FRP | LSZH/PE |
| Unitube flat | Low-count, easy strip | FRP/Steel | LSZH or PE |
Production line equipment that ensures quality and speed
Automation and sensor-driven feedback at Shanghai Weiye OFC Equipment cut manual handling and increase throughput for drop patch preparation.
Our production line uses automated machines that cut/strip drop cords to increase output and cut labor variability.
The CLX-BPO2 automated stripper runs under PLC and photoelectric control. One cycle is ~1.5 s, giving real-world speeds near 20 terminal operations per minute.
Automated Cut/Strip for Drop Cords
The equipment strips LSZH and PVC jackets and trims FRP or steel strength members to precise stub lengths. Cylinder-driven actuators provide quick, repeatable motion and low downtime.
Closed-Loop Control for Repeatability
PLC logic and photoelectric sensors deliver precise positioning and feedback control. Inline checks feed control charts so operators can correct trends before defects grow.
| Feature | Capability | Result |
|---|---|---|
| Machine | 1.5s cycle, auto-strip | ~20 terminals/minute throughput |
| Actuation | Cylinder-based | High speed and reliability |
| Material handling | LSZH/PVC; FRP/steel | Clean, accurate preps |
| Process control | PLC/photoelectric with in-line SPC | Stable quality, reduced rework |
- Auto scrap ejection and ergonomic loading maintain clean workcells.
- PCPs document calibration and key parameters.
- Combined machines, fixtures, and trained staff help meet FTTH volume goals without sacrificing accuracy.
What the CLX-BPO2 Adds
The CLX-BPO2 provides industrial-grade strip/trim to our line, cutting cycle time while keeping prep consistent.
Shanghai Weiye OFC Equipment deploys the CLX-BPO2 to raise output and standardize prep quality. The unit runs at an approximate cycle time of 1.5 seconds, producing around 20 preps per minute in production.
PLC/photoelectric control deliver exact detection and repeatable actuation. That control helps keep strip lengths and reserved strength stubs within tight tolerances.
Throughput & Cycle Time
Typical operation speed is ~1.5 seconds per cycle. This enables steady throughput under normal production conditions.
Supported jacket and reserved strength lengths
The CLX-BPO2 handles LSZH/PVC with an adjustable jacket strip length from 17.5–35.0 mm. Reserved stubs are set between 7.0 and 11.0 mm to fit common termination hardware.
Handling FRP and steel wire strength members
The machine cleanly cuts FRP and steel wire strength elements while protecting neighboring fibers. Customized cutters are available for non-standard cross-sections to preserve precision.
- Auto-eject scrap and sensor start reduce idle time.
- Compact size (L40 × W18 × H18 cm), 110–220V, 50W, and 11 kg mass simplify cell integration.
- Pneumatic cylinders and closed-loop control boost reliability and reduce maintenance downtime.
| Specification | Value | Benefit |
|---|---|---|
| Cycle | ~1.5 s (~20/min) | Supports high-volume runs |
| Strip lengths (A) | 17.5–35.0 mm | Compatible with common connectors |
| Reserved stub (B) | 7.0–11.0 mm | Meets strength and termination needs |
| Power & size | 110–220V, 50W; 40×18×18 cm | Easy integration into existing equipment |
Using this machine, Shanghai Weiye OFC Equipment standardizes terminal prep so field teams receive drop parts ready for quick installation. The CLX-BPO2 supports our lines in meeting volume targets without compromising quality.
Customized specifications to fit your FTTH system
Shanghai Weiye OFC Equipment configures every order to fit your network requirements and simplify deployment. We combine focused options with predictable schedules so your teams get install-ready reels.
Choose 1 to 4 cores with single-mode or multimode fiber. Options include OS1, OS2, and OM2–OM4 plus G.652D and G.657 variants to match your optics and connector plans.
We match sheath colors to Pantone codes for fast field ID and consistent asset tagging.
Jackets, Legends & Branding
Select LSZH, PVC, or PE jackets based on route and safety rules. Custom legends/logos support inventory and warranty tracking.
Put-Ups, Packaging, and Structures
Standard put-ups are 1/2/4 km with tailored reels and packaging to fit storage/handling. Choose bow-type flat or self-supporting designs and FRP or steel members to fit span and isolation requirements.
| Choice | Typical | Advantage |
|---|---|---|
| Length | 1 / 2 / 4 km | Less staging, easier reels |
| Jacket | LSZH / PE / PVC | Indoor/outdoor compatibility |
| Structure | Bow-type / Self-supporting | Flexible routing/span |
As a supplier, Shanghai Weiye aligns runs to your schedule and provides docs that lists final specifications for straightforward QA on site.
Quality assurance, testing, and documentation
Shanghai Weiye OFC Equipment embeds quality checkpoints across the production line so every item has recorded acceptance data at ship.
Lab Testing: Heat, Salt Spray & Vibration
Our lab conducts elevated-temperature exposure, salt spray corrosion, and vibration tests to qualify materials/assemblies. These tests simulate field stresses for indoor and outdoor use.
Full Test Reports for Every Reel
Every fiber optic cable ships with a 100% test report that logs attenuation, return loss, and geometry where applicable. Final QC gates prevent nonconforming shipments before they leave the factory.
Traceability and compliance
Batch records link tests to reels/serials so audits and claims are easy to verify. Documentation uses standard customer templates to accelerate approvals and receiving inspection.
- Line checks and final inspection reduce field failures and cut warranty events.
- Quality packages include specifications confirmation and formatted data for quick review.
- Ongoing trend analysis drive preventive maintenance and raise long-term reliability.
| Test | Purpose | Outcome |
|---|---|---|
| High-temperature | Material stability | Pass at target temperature |
| Salt spray | Corrosion resistance | Qualified for outdoor use |
| Vibration | Mechanical robustness | Improved field reliability |
FTTH Drop Cable Pricing & Cost Drivers
Budget planning for a drop starts with fiber and jacket choices and is refined by volume and customization.
Typical prices vary widely—from about $30 to $1,000 per unit—based on fiber grade (G.652/G.657/OM2–OM4), jacket chemistry (LSZH, PVC, PE), reel length, and structural design.
Materials, Grade, Jacket & Structure
The primary cost drivers are fiber grade, sheath material, and the structural type chosen for deployment.
Self-supporting designs and steel members increase material/labor. Custom sheath colors/logos/legends add setup and impact pricing on small runs.
Length/Volume/Customization Impact
Longer put-ups and larger volumes reduce unit cost. Small quantities often carry setup fees and higher unit prices.
- Line changeovers and custom tooling increase lead time and add to cost.
- Clear RFQs and line scheduling let Shanghai Weiye OFC Equipment align price quotes to delivery windows.
- Framework agreements and indexed pricing stabilize budgets over phases.
| Driver | Effect on price | Guidance |
|---|---|---|
| Fiber grade | Large | Right-size spec to budget |
| Sheath material | Medium | Compare LSZH vs. PE for total cost |
| Order length / volume | Large | Consolidate where possible |
Logistics for the U.S.
Shanghai Weiye OFC Equipment keeps lead times/logistics clear so planners can align crews and sites. Predictable schedules reduce downtime and help control cost when a rollout is underway.
Typical production windows and capacity planning
Typical production windows run 4–5 days for orders under 100 km and 7–10 days for < 500 km. We plan capacity to track your milestones and to maintain on-time delivery.
The service team issues production updates and tracking so installation teams can plan arrivals. For tight schedules, we hold contingency capacity to accelerate critical-path orders.
Why MOQ Matters
The MOQ is 1 km. This reflects setup needs such as wire/die adjustments that consume start-up material and scrap.
We review your put-ups and staging to select reels to reduce waste/handling. Staggered batches can balance inventory holding with frequent, smaller deliveries to job sites.
Installation Scenarios & Readiness
On-site conditions determine whether a self-supporting aerial, ducted pull, or direct burial is the best fit for a project.
Aerial, duct, and direct-buried deployment considerations
For aerial runs, Shanghai Weiye OFC Equipment recommends self-supporting designs with correct strength members to control sag and tension for long-term stability.
Duct installations perform best with low-friction jackets and crush-resistant constructs so pulling avoids fiber damage. PE jackets are common for underground and buried paths where moisture resistance is needed.
Direct-buried designs require proper depth control per local codes and moisture barriers to protect the fiber core long-term.
Indoor riser/plenum distribution and ONT termination
Indoor riser and plenum routes prefer LSZH to meet smoke/flame codes. Flat drop profiles strip cleanly and present controlled stubs for fast ONT terminations.
We guide the choice of steel or FRP (dielectric) strength members based on bonding requirements, lightning exposure, and hardware compatibility. Standardized prep from the production line reduces install time and reduces scrap.
| Deployment | Key feature | Installer note |
|---|---|---|
| Aerial | Self-supporting (steel/FRP) | Verify messenger hardware/tension |
| Duct | Low-friction, crush-resistant | Use pull tape + lubricant |
| Direct-buried | PE jacket, moisture barrier | Follow depth/warning tape codes |
| Interior | LSZH with tight-bend support | Maintain bend radius at penetrations |
Our approach ensures a consistent install experience across indoor/outdoor transitions. That leads to fewer callbacks, speeds activations, and stable field performance for your system.
Support from Spec to Service
Our team coordinates tests, line schedules, and installation guidance to avoid surprises in deployment.
Shanghai Weiye OFC Equipment provides engineering support from early requirements through approved drawings and pilot builds. We deliver documentation templates and clear installation notes so field crews work from the same plan.
After-sales service includes fast response, RCA, and corrective action. All products ship with full reports and traceability to support QA acceptance.
- Round-the-clock availability for status and technical support.
- Warranty with free replacement if any quality problems are confirmed.
- Schedule coordination for urgent changes or acceleration requests.
- Config control so shipped items match agreed requirements every time.
| Area | What we do | Benefit |
|---|---|---|
| Engineering | Spec review & pre-production builds | Fewer field issues |
| Testing | Lab trials & 100% test reports | Traceable quality |
| Service | Rapid replacement & root-cause | Minimized downtime |
Wrap-Up
Select Shanghai Weiye OFC Equipment for custom drops, quick lead times, and full traceability.
We provide custom FTTH drops that pair material choices with validated manufacturing and lab testing. Every reel ships with a 100% test report and documented lab trials to support U.S. field acceptance.
A robust production line, including CLX-BPO2-enabled prep machines, cuts variability and shortens turnaround. Our equipment set standardize strip and stub lengths so installers see consistent results at turn-up.
From fiber selection through jacket, printing, and packaging, we balance design and cost to extend service life. Dedicated customer support guides scheduling, logistics, and after-sales care so your deployment remains on plan.
Get in touch with Shanghai Weiye OFC Equipment to align specs, timeline, and volume. We stand behind every shipment with laboratory validation and responsive support.
